Our mounting systems compared

The Quick-Lock mounting systems on ORTLIEB bike bags allow the bags to be attached to bike racks quickly and securely. They are also known as self-locking mounting systems, because bike bags equipped with this system can be hooked onto the rack easily and securely. All mounting components are very easy to replace in the event of damage.

Quick-Lock3.1

Quick-Lock2.2

Quick-Lock2.1

The QL3.1 system secures the bag to the rack particularly quickly and easily and offers excellent carrying comfort away from the bike.

The evolution of the QL2.1 system, with higher payload and quick switching between different bikes.

ORTLIEB’s most proven mounting system, trusted by millions of satisfied cyclists.

Feature

Back of bag is free of protruding hooks

Quick, tool-free adjustment without reducer inserts

Tool-free adjustment

Maximum payload

9 kg

12.5 kg

9 kg

Compatible racks

For racks with QL3.1-compatible mounting points. Can also be retrofitted with the QL3.1 Mounting Set.

Compatible with all conventional luggage racks

Compatible tube diameters

8–16 mm (with QL3.1 Mounting Set)

8–20 mm

The QL3.1 Mounting Set can be attached to racks with a tube diameter of up to 16 mm. For tube diameters from 11 to 16 mm, the adapter clamps are also required.

The hooks can be adjusted tool-free between 10 and 16 mm in 1 mm increments. With the QL2.1 hooks, 18 or 20 mm tubes can also be used.

The 16 mm hooks can be adjusted to 8, 10 and 12 mm using the included reducer inserts. With the QL2.1 hooks and anchoring hooks, 18 or 20 mm tubes can also be used.

More features

Lockable

—

with the QL2-Lock or the anti-theft device

(not included)

with the QL2-Lock or the anti-theft device

(not included)

One-handed operation possible

Mounting components

On the rack

On the bag

Anti-scratch coating
